Garrett GTX3071R GEN 2 Turbo Turbocharger T3 Vband 851154-5002S

£1,850.00

Garrett GEN2 GTX3071R dual ball bearing turbocharger. Advanced GEN2 billet compressor wheel capable of 650HP!

The Garrett GEN2 GTX3071R fits turbine housings for Garrett GT30 (standard size) and GTX30 series turbochargers with a 60mm inducer and 84 trim turbine wheel.

PRODUCT FEATURES:
Advanced aerodynamics & ultra high flow Garrett GTX GEN2 compressor wheelForged billet aluminum compressor wheelDual ball bearing CHRA rotating assembly

PRODUCT SPECIFICATIONS:
Compressor Wheel Inducer: 54mmCompressor Wheel Exducer: 71mmCompressor Wheel Trim: 58Compressor Housing A/R: 0.60Turbine Wheel Inducer: 60mmTurbine Wheel Exducer: 55mmTurbine Wheel Trim: 84

COMPRESSOR HOUSING OPTIONS:
T04E Frame, 4 inch inlet, 2 inch outlet, and machined ported shroud (standard/default option)T04B Frame, 3 inch inlet and 2 inch outlet (Alternate compact option, same layout as GT2860RS/GT2871R)

TURBINE HOUSING OPTIONS:
Ni-Resist V-Band Inlet & Outlet. Available in .61, .83 or 1.01 A/R

ALTERNATIVE TURBINE HOUSING OPTIONS:
T25 and T3 .61, .83 and 1.01.
